CUSTOM ITEM: Tubing connector fittings, high pressure, two pieces, 1/16 inch, PEEK, natural, large head, standard length and 10-32 screw threads. Use with Single Cone Ferrules. Finger tighten, ARE-Applied Research brand. Bulk Price.
Additional Info:
PEEK tubing connector fittings for 1/16" OD tubing provide reliable connections in high‑pressure HPLC systems. Designed for standard 10‑32 ports, these fittings are compatible with many analytical HPLC fluidic configurations requiring chemically resistant, metal‑free flow path components.
The 47320‑32 features a large head design and standard length configuration for convenient finger tightening during routine installation and maintenance procedures. This two‑piece fitting is designed specifically for use with single cone ferrules in high‑pressure analytical applications.
Key Benefits
Large head design for easier finger tightening
Two‑piece configuration for flexible installation
Standard length fitting geometry
Compatible with single cone ferrules
Natural PEEK construction for chemical resistance
Suitable for high‑pressure HPLC applications
Bulk pricing available for laboratory and OEM requirements
Specifications
Material: Natural PEEK
Tubing Size: 1/16" OD
Thread: 10‑32
Head Type: Large head
Configuration: Two‑piece
Length: Standard length
Tightening Method: Finger tighten
Ferrule Compatibility: Single cone ferrules
Usage Notes
For high‑pressure HPLC applications
Designed for analytical HPLC systems
Intended for use with single cone ferrules
Not recommended for UHPLC applications
