Catalog Number - 40031-PG1

40031-PG1 Cogent UDA™ (WCX) Guard Column Starter Set provides everything needed to begin protecting analytical columns while maintaining the unique mixed‑mode selectivity of the UDA™ stationary phase.

This kit includes a stainless steel guard column holder and five guard column cartridges, each packed with 4 µm, 100 Å Cogent UDA™ (WCX) TYPE‑C silica. These cartridges utilize the same Undecanoic Acid ligand chemistry as the analytical columns, ensuring consistent chromatographic behavior.

The UDA™ stationary phase features an 11‑carbon hydrophobic chain with a terminal carboxylic acid group, enabling:

• Reversed phase (hydrophobic interactions)

• Weak cation exchange (active at pH ≥ 6)

• HILIC (polar interaction capability)

This matched chemistry ensures that while contaminants are trapped, method selectivity and retention remain consistent.

Each cartridge is packaged individually in protective, resealable Delrin cases, preventing drying or damage prior to use.

2.1 mm ID System Compatibility – Low‑Flow Protection

Designed specifically for narrow‑bore analytical columns.

• Optimized for 2.1 mm ID analytical columns

• Maintains low dispersion for LC‑MS and UHPLC workflows

• Protects against particulates and strongly retained contaminants

• Preserves column performance and efficiency

✅ Recommended for all UDA™ analytical workflows using 2.1 mm ID columns

Flow Rate & System Requirements (2.1 mm ID, 4 µm)

⚠️ Requires low‑flow capable HPLC or UHPLC system

• Typical flow rate range: ~0.2 – 0.4 mL/min

• Moderate backpressure (4 µm particles)

• Designed for low‑dispersion systems

• Compatible with UV and MS detection

✅ Important: Systems must provide stable low‑flow performance for 2.1 mm ID columns

✅ Best Practice: Replace cartridges regularly to maintain protection and chromatographic integrity

Why Use UDA™ Guard Columns

Protects Analytical Columns

• Prevents contamination from particulates and matrix components

• Reduces irreversible adsorption of strongly retained compounds

Maintains Method Selectivity

• Matches UDA™ mixed‑mode chemistry (RP, WCX, HILIC)

• Ensures consistent retention and reproducibility

Extends Column Lifetime

• Reduces column replacement frequency

• Improves method robustness

TYPE‑C Silica Advantages

Faster Equilibration

• Reduces downtime between runs

No Strict Moisture Control (HILIC)

• Simplifies mobile phase preparation

Extreme Robustness

• Stable at low pH (<2)

• Resistant to hydrolysis

Long Cartridge Life

• Durable under routine analytical use

Cogent UDA™ Guard Kit Advantages

Complete Starter Solution

• Includes holder and cartridges

Matched Chemistry

• Ensures seamless method compatibility

Convenient Packaging

• Individual cartridge storage cases preserve performance

Optimized for LC‑MS Workflows

• Low dispersion and MS compatibility

Typical Applications

• LC‑MS analytical workflows

• Complex matrix separations

• Method development and routine testing

• Basic and ionizable compound analysis

• Pharmaceutical and bioanalytical workflows

Important Usage Notes

• Designed for 2.1 mm ID analytical columns only

• Replace cartridge when backpressure increases or performance decreases

• Ensure holder is properly installed for optimal performance

• Store unused cartridges in protective cases
