Column Inline Filter, for HPLC columns, replaceable filters and All-PEEK holder. Includes 25 disposable 2 um Ti filters. ARE-Applied Research brand. Bulk Price.
Additional Info:
The 49680‑02S Inline Column Filter System is an economical, reusable solution for protecting analytical HPLC columns and instruments from particulate contamination. This system combines a reusable all‑PEEK filter holder with replaceable PEEK‑encased titanium filter elements, delivering reliable pre‑column protection while reducing disposable hardware waste.
Designed for typical analytical HPLC flow rates, the system is compatible with columns operating up to 4,500 psi and 5 mL/min, making it suitable for routine HPLC workflows. It is not recommended for UHPLC pressure ranges.
The supplied 2.0 µm titanium filter discs effectively trap undissolved particles and pump‑seal debris before they can damage injectors or analytical columns. When backpressure increases, the filter holder is simply disconnected, the spent filter replaced, and normal operation resumed—no disposal of the holder required.
Key Features
Reusable In‑Line Filter Holder
Durable all‑PEEK holder for long service life
Bio‑inert construction (PEEK + titanium)
Reduces consumable cost compared to fully disposable filters
Replaceable 2.0 µm Titanium Filters
Includes 25 disposable PEEK‑encased titanium filters
Effective particulate removal with low pressure impact
Designed for routine analytical HPLC protection
Universal HPLC Compatibility
Fits all standard HPLC column threads and pilot lengths
Can be hand‑tightened or wrench‑tightened
Easy to integrate into existing systems
Instrument & Column Protection
Installed after the pump, before the injector
Helps protect injectors, frits, and column beds
Extends column lifetime and improves method robustness
Usage & Replacement Guidance
Monitor system backpressure during operation. A rising pressure typically indicates filter loading.
To replace a filter:
Reduce system pressure to atmospheric
Disconnect the inline filter holder
Remove and discard the used filter disc
Insert a new filter and reconnect
The system accepts any PEEK‑encased filter disc that is ¼ inch OD × 1⁄16 inch thick, allowing flexibility in filter porosity selection.
Pressure Rating & Compatibility
Maximum pressure: 4,500 psi
Maximum recommended flow: 5 mL/min
Compatible with: Analytical HPLC systems
Not recommended for: UHPLC pressure ranges
An economical 10‑pack of replacement filters is available separately.
Typical Applications
Routine analytical HPLC
Injector and column protection
Method development and validation
Cost‑controlled laboratory environments
Bio‑inert chromatography workflows
Bulk Order & Pricing Information
This is a custom, made‑to‑order item.
Orders cannot be canceled once placed
Custom items are non‑returnable
