Tubing Connector Nuts, low pressure, 1/16 inches, Delrin, mixed colors with 1/4-28 screw threads, for use with flange free, polymeric tubing. ARE-Applied Research brand. 10/PK.
Additional Info:
The 45216‑X‑K Delrin Tubing Connector Nuts (10/Pack) are low-pressure fluidic fittings designed for connecting 1/16 inch OD flangeless polymeric tubing in HPLC systems and other fluid handling applications. These finger-tightened connector nuts provide a fast, reliable connection method without requiring tubing flanging.
This configuration includes mixed colors within each package, allowing easy visual identification of flow paths, systems, or users while maintaining consistent performance.
Manufactured from Delrin™ (polyoxymethylene), these fittings offer high stiffness, low friction, and excellent dimensional stability, making them ideal for routine use in low-pressure flow paths.
✅ Key Benefits
Flangeless Connection Design Eliminates the need for tubing flanging
Finger-Tight Installation Quick, tool-free connections
Standard 1/4‑28 Thread Compatibility Fits common low-pressure HPLC ports
Mixed Color Set Enables easy visual identification and system organization
Durable Delrin Construction Provides strength, rigidity, and dimensional stability
10/Pack Configuration Ideal for routine operations and multi-line setups
Performance & Design
Material: Delrin™ (Polyoxymethylene)
High stiffness and strength
Low friction characteristics
Excellent dimensional stability
Color: Mixed (assorted in pack)
Connection Type:
1/4‑28 UNF threaded nut
Designed for flangeless tubing systems
Engineered for:
Quick, tool-free installation
Reliable sealing when used with proper ferrules
Consistent performance in low-pressure environments
System Role & Integration
Connects 1/16" OD polymeric tubing to HPLC system ports
Requires separate ferrules for proper sealing
Used in:
Multi-line or multi-user HPLC systems
Sample prep and transfer lines
General laboratory fluidic workflows
⚠️ Usage Notes
Tubing must NOT be flanged (flangeless only)
Ferrules are required for proper sealing
Designed for low-pressure applications only
Pressure Limit: ~500 psi (34.5 bar)
Maximum Temperature: 100°C
⚠️ Avoid exposure to:
Chlorinated solvents
Strong acids (Delrin material sensitivity)
Specifications
Product Type: Tubing Connector Nuts
Material: Delrin™ (Polyoxymethylene)
Color: Mixed (assorted)
Tubing Size: 1/16 inch OD
Thread Type: 1/4‑28 UNF
Connection Type: Flangeless
Pressure Limit: ~500 psi (34.5 bar)
Max Temperature: 100°C
System Type: Low pressure
Pack Size: 10 per pack
Brand: ARE‑Applied Research™
