Catalog Number - 75040-05P

Cogent HPS Amino™ HPLC Columns are designed for the analysis of highly polar compounds using Normal Phase and HILIC chromatography modes. Manufactured using tri-functional bonding of a three-carbon silane with a terminal amino functional group bonded to high-purity silica, this stationary phase is not end capped and provides the selectivity required for challenging separations of carbohydrates, sugars, organic acids, and other polar analytes. HPS Amino™ is widely used as an alternative for USP L8 methods and for new method development requiring amino phase selectivity.

75040-05P is packed with 5 µm HPS Amino™ particles in a 4.6 mm ID x 50 mm analytical format. The short 50 mm length is optimized for rapid analysis, method development, and high-throughput screening applications where fast cycle times and reduced solvent consumption are important. The 5 µm particle size provides reliable efficiency with lower operating backpressure compared to smaller particle columns, making it suitable for conventional HPLC systems.

The HPS Amino™ stationary phase is particularly effective for negatively charged polar compounds, including sugars and compounds containing carboxylic acid functional groups. It is commonly used in Normal Phase and HILIC separations where retention of highly polar analytes is required. This column is also frequently selected for scouting methods and initial method development studies due to its unique selectivity and broad applicability.

Key Benefits

• HPS Amino™ stationary phase

• USP L8 equivalent chemistry

• Tri-functional amino bonding

• High-purity silica support

• 5 µm particle size

• Suitable for HILIC separations

• Suitable for Normal Phase chromatography

• Lower operating backpressure

• Excellent for sugars and organic acids

• Ideal for rapid method development

Typical Applications

• USP L8 methods

• HILIC chromatography

• Normal Phase HPLC

• Sugar analysis

• Carbohydrate analysis

• Organic acid analysis

• Polar compound separations

• Food and beverage testing

• Method development

• Scouting studies

Specifications

• Product Type: Analytical HPLC Column

• Stationary Phase: HPS Amino™

• USP Classification: L8

• Chromatography Modes: HILIC and Normal Phase

• Particle Size: 5 µm

• Pore Size: 120Å

• Column Dimensions: 4.6 mm ID x 50 mm

• Recommended Flow Rate: 1.0–2.0 mL/min

• Column Hardware: Stainless Steel

• Brand: Cogent

Important Notes

• Suitable for HILIC and Normal Phase chromatography

• USP L8 equivalent chemistry

• Not end capped

• Designed for polar and negatively charged compounds

• Excellent for sugars and compounds containing carboxylic acid groups

• Compatible with standard analytical HPLC systems

• Ideal for rapid method development and screening

• Frequently compared with Inertsil™ Amino and Luna™ Amino columns

• Lower backpressure than smaller particle columns

• 50 mm length minimizes analysis time and solvent consumption

  ---
